Mobile Computing Platform Qualcomm® MSM8909 Quad-core processor, 1.1GHz
Operating System Android™ 8.1
LCD 7″ HD (1280 x 720), anti-reflective, daylight viewable
Touchscreen 10 point multi touch capacitive touchscreen supporting glove and rain mode
RAM 2 GB
Storage 16 GB eMMC
Storage Expansion Micro SDXC card slot
Barcode Reader (optional) 1D, 2D Support
Camera Rear: 8 MP rear camera with LED light
Bluetooth® v4.2 Class 1
WLAN Qualcomm® WCN3660B (a/b/g/n/d/h/i/r)
Mobile Broadband (optional) LTE, HSPA+, UMTS, EDGE, GPRS, GSM (Data and Voice)
Dedicated GPS Yes
NFC Yes (Supports Type A,B, FeliCa, ISO15693)
Sound Mono Speaker and x2 internal microphones
Interfaces
- Micro USB 2.0: x1 (For charging and data transfer)
- Docking connector: x1
- Headset jack: x1
Sensors
- Acceleration sensors,
- ambient light sensor
Power
- Battery: User replaceable Li-ion 3200 mAh with warm swap function
- Battery operating time: 9 hours
- Battery charging time: With Cradle: Full charge in Approx. 2.5 hours (TBD)
- With micro USB port: Full charge in Approx. 4 hours (TBD)
- AC Adapter (available as accessory): USB charger and USB cable (5V 1.8A)
Buttons:
- User configurable scan buttons: (Only with optional barcode reader) x2
- Power on/off button: x1
- Volume buttons: x2
Physical Dimensions (WxDxH) 193 mm x 131mm x 13 mm (30mm with barcode reader)
Weight Approx. 440g (Wi-Fi & 4G model), 480g (Including barcode reader)
Testing Standards
- MIL-STD 810G certified
- Gravity drop resistance test: 150cm*
- Vibration test: MIL-STD 810G*
- Dust resistance test: IP-6X*
- Water resistance test: IP-X7*
- Operating temperature: -10°C to +50°C**
- Storage temperature: -30°C to +70°C**
